MIDDLE- AND HIGH-VOLTAGE CV/CC POWER SUPPLY

NGR SERIES

MSA and NGR series are middle- to high-voltage DC CV power supplies for research and development of electron tube circuits and electrolytic capacitors. The system is protected from overcurrent by CC drooping and is reset automatically, so it can be used under any loadconditions. The main circuit control uses middle-frequency oscillation, and therefore the products are all very light and compact. Noise from the power source has been reduced significantly

Optional

● Digital panel meters.
● Digital control function.
● Positive/negative switching mechanism.
● Negative grounding.

Individual Specifications

Output voltageModel	0～550V
NGR-1	modelNGR-550-02NGR-550-05
NGR-2	modelNGR-550-10

Common specifications

Input power	1-phase 100V or 200V AC±10%, 50Hz or 60Hz.
Output current stability	±0.5% of present value + 3mA.
Overcurrent protection	CC drooping, automatic reset (crossover method).
