POWER-AMPLIFIER-TYPE AC STABILIZED POWER SUPPLY

APS SERIES

Using a 10-rotation potentiometer, output voltage can be set to any desired value from 1V to 120V or from 2V to 240V.

Capable of supplying up to 2.5 times the rated current to a load as peak or rush current.

Mean current and peak current detection circuits are installed for protection.

Output frequency can be changed by replacing the frequency units (45-65Hz, 48~480Hz and 400Hz).

Individual Specifications

Output voltage Output capacity	Model
300VA	modelAPS-300
500VA	modelAPS-500
1000VA	modelAPS-1000
2000VA	modelAPS-2000
3000VA	modelAPS-3000
